Professional Customized 8MP 4K IMX415 Camera Module Support Face Recognition

Product category:

Quantity	Price
1 - 99	$40.80
100 - 499	$36.80
500 - Unlimited	$33.00

full product footer

Description

Product Parameter

Product Name	8MP 4K IMX415 Camera Module
Module No	HBVCAM-4K2246 V11-95
Module Size	38mm × 38mm × 24.20mm±0.5MM
specificities	1. Standard industrial camera 38, 32mm plate structure 2. The main promotion has requirements for high pixel effect, large screen 4k screen, and live streaming camera 3. Integrated dual digital microphone 4. The new generation 4K camera module has better relative performance, price, and performance
Temperature (Operation)	-30°C to 70°C
Temperature (Stable Image)	0°C to 50°C
Assembly technique	SMT (ROSH)
Focus	Fixed
Object distance	30CM-infinity
Resolution	600LW/PH (Center)
PCB printing ink	Black
interface	USB2.0
Power suuply	USB bus power
supply voltage	DC 5V±5%
Maximum Power consumption	1330 mW
Operating system request	Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc
Sensor	IMX415 (1/2.8” )
Seneor Package	PLCC,Bare Die
Maximum resolution	3840*2160
Sensitivity	2000mV /（lux-sec）
Pixel Size	1.0µm x 1.0µm
Maximum Image Transfer Rate	MJPEG 1280x720 30FPS / YUY2 1280x720 10FPS MJPEG 1920x1080 30FPS / YUY2 1920x1080 3FPS MJPEG 2048x1536 30FPS / YUY2 2048x1536 3FPS MJPEG 2880x2160 30FPS / YUY2 2880x2160 1FPS MJPEG 3840x2160 30FPS / YUY2 3840x2160 1FPS
S/N Ratio	46db
Max Dynamic Range	72db
Shutter type	Electronic rolling shutter
AGC/AEC/Whiter balance	Auto
Output Formats	YUY2/MJPEG
Microphone	Support
Lens Construction	6G
F/No	2.0
EFL	4.0 mm
FOV	95°
TV Distortion	<-13.5%
Relative Illumination (Sensor)	70%
IR Filter	650±10nm
Module Package	Anti-electrostatic tray
Certifications	FCC/CE/ROHS

Packing&Shipping

We focus on environmental protection and balance the choice of product packaging between product safety and environmental impact.Of course, we can also accept your customized packaging requirements.For transportation.Air, express, land and sea transportation, we support.First of all, we will measure and recommend to you according to the quantity of the product, your acceptable arrival time, and the logistics price. Your own freight forwarder is also acceptable.

Company Profile

00:0002:00

FAQ

1. who are we?
We are based in Guangdong, China, start from 2013,sell to Domestic Market(41.00%),North America(15.00%),Eastern
Europe(13.00%),Eastern Asia(10.00%),Western Europe(5.00%),Oceania(5.00%),Southeast Asia(3.00%),Southern Europe(2.00%),South
America(2.00%),South Asia(2.00%),Northern Europe(1.00%),Mid East(1.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.

3.what can you buy from us?
USB Camera Module,Raspberry pi Camera Module,Endoscope Camera Module,Dual Camera Module,Webcam Camera Module.

4. why should you buy from us not from other suppliers?
Huiber Vision Technology Co., Limited is an outstanding CMOS camera module designer and manufacturer. We have first-class
technology development capability, advanced testing equipment, complete production lines and manufacturing process management.

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Escrow;
Language Spoken:English,Chinese.
