5MP Fixed Focus OV5640 Sensor Maximum Resolution 2592*1944 CMOS Camera Module

Product category:

USB Camera Board

SKU:

216934

Price:

$24.00

Description

Product Description

Module No.	BM1466FF S1.0
Module Size	68.2mm × 26mm × 6mm±0.2MM
Temperature (Operation)	-30°C to 70°C
Temperature (Stable Image)	0°C to 50°C
Assembly technique	SMT (ROSH)
Focus	Fixed
Object distance	30CM-infinity
Resolution	800LW/PH (Center)
PCB printing ink	Black
interface	USB 2.0
Power suuply	USB bus power
supply voltage	DC 5V±5%
Maximum Power consumption	940 mW
Operating system request	Win XP/win 7,8 / vista /android 4.0/ mac /Linux with uvc
Sensor	OV5640 (1/4" )
Seneor Package	CSP,Bare Die
Maximum resolution	2592*1944
Sensitivity	600mv /(lux-sec)
Pixel Size	1.4µm x 1.4µm
Maximum Image Transfer Rate	MJPEG 1024x768 30FPS / YUY2 160x120 30FPS
	MJPEG 1280x720 40FPS / YUY2 320x240 30FPS
	MJPEG 1600x1200 30FPS / YUY2 640x480 30FPS
	MJPEG 1920x1080 15FPS / YUY2 800x600 30FPS
	MJPEG 2048x1536 15FPS / YUY2 1024x768 15FPS
	MJPEG 2592x1944 15FPS / YUY2 2592x1944 3FPS
Output Formats	YUY2/MJPEG
EFL	3.3 mm
FOV	60°
Certifications	FCC/CE/ROSH

Effect Picture
