32x32mm MINI size 4MP H.264 H.265 Low Illumination network IP Camera module Board

Product category:

Camera Board

SKU:

200944

Price:

$8.00

Description

Model No.	H4C
Module	Fullhan 2K DSP+1/2.9" 4MP CMOS
LUX	COLOR 0.05Lux@F1.2; B/W 0.005Lux@F1.2;
S/N	≥50db(AGC OFF)
WDR	DWDR; ＞80db
Audio Input	1CH MIC Input
LED Board Function	CDS IR LED, Warm LED, White LED,Sensor Control
IO port	1CH RESET, IR CUT, Alarm Input/Output
Coding Format	H.265/H.264
Main Steam	25601440，1-30FPS/S 23041296、19201080、1280720，1-30 FPS/S
Sub steam	704576、800448、640480、640360、352*288，1-30FPS/S
Video Coding Compression	128Kbps-8192bps continuous adjustable
Subtitle Overlay	Support Channel Name、Date & Time、Frame、Resolution、4 lines of character overlay
Data Record	Video, picture
Storage Method	Cycling Recording, Alarm Recording
Alarm Transfer	IO output, browser, management software
Protocol	ONVIF
Mobile	Support IOS, Android
Browser	Support IE6.0 and above browser(insert Web Server),support 10 visitors in the same time(MAX)
Mobile Client	Support iPhone、iPad、Android
Temperature	-30℃ - +60℃
Humidity	0% - 90%
Power	DC12V-120mA
power	1.3W
size	32* 32*10mm (without lens)
Weight	10g
